High Precision MDF Metal Robotic Welding Machine Industrial Robotic Arm 130W 150W

Product Details:
Place of Origin: wuxi, china
Brand Name: CMC
Certification: ISO,CE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: according to the machine requirement
Packaging Details: Suitable for container shipping
Delivery Time: according to the machine requirment
Payment Terms: Down payment 30% T/T, 70% T/T before shipping
Supply Ability: According requirement

Detail Information

High Light:

Robotic Laser Welding


Robotic Welding Equipment

Product Description

 130W 150W High Precision and High Speed used welding robot for MDF Metal
Hassle-free operation
Equipped standard with a simplified teaching screen that is dedicated to welding and easy operation, the system conducts welding like a skilled human welder. The teach pendant is even equipped with an easy-to-view, easy-to-operate color LCD touch-screen.
Optimized welding machine connected via a single cable
With a built-in interface dedicated to welding machine, the system can readily be linked to the robots via a single cable.
Your welding conditions are stored and can be called up as a data base
Welding conditions can be classified and registered in a database, where they are ready to be used again whenever needed at the touch of a button.
Minor stoppages have been substantially reduced
The system comes equipped standard with a dedicated start sequence function that improves the arc start ratio, as well as a restart sequence function that sends the robot back to the point where welding was interrupted and automatically conducts overlapped welding, thereby restarting the welding operation.
A full section of specific options
(1) Servo-torch, (2) Touch-sensing (15VDC; 400VDC), (3) Special weaving pattern, (4) RTPM (Arc sensor), (5) Start-point sensing, (6) Multilayer welding function, (7) AVC (Arc-sensor dedicated to TIG welding), and more.
Allows use in environment with a lot of electrical noise
The system incorporates a range of innovations, developed from the design phase to cope with noise generation in TIG welding, plasma cutting, etc., so it can be operated without about having to worry about noise-related constraints.
Realize a fully “Teaching-less” welding system
Combining the robots with KCONG realizes a fully “Teaching-less” welding system.

Optional equipment

JT1 : 360° 118 120

410 JT4 : ±360°
JT2 : 135°

P JT5 : ±145°

JT6 : ±360°

4-M5 Dp8 ø0.2 X Y

• Shock sensor
• Torch bracket (350 A/500 A)
• Installation base (600mm/300mm)
• Base plate (750mm×750mm×25mm)
• Liner slide
• Positioner
• Servo-torch
• RTPM (Arc sensor)
• AVC (Arc-sensor dedicated to TIG welding) • 3D laser sensor
• Wall mounting


The following materials can be cut or engraved by a laser cutting machine smoothly with a perfect effect.

Acrylic, Plexiglass, Pmma, Perspex, Organic board, Double color plateYesYes
Plastic, PP, PET, PC, PMMA, PS, PES, PA, Plastic Foils&Films, Polycarbonate, polyester or polyimide membrane keyboardsYesYes
Wood, Bamboo, Veneer, MDF, Blasa wood, PlywoodYesYes
Leather, Pig leather, Cow Leather, Sheep leatherYesYes
Textile, cotton, silk, felt, lace, synthetic & technical textiles, aramid, polyester, fleeceYesYes
Foam & Filter, Mats Polyester (PES), Polyethylene (PE), Polyurethane (PUR)
Paper, Cardboard, Chipboard, Press BoardYesYes
Stone, Ceramic, Granite, Marble, Natural stone, Pebble stone, SlateNoYes
Rubber stamps, Synthetic & Silicone Rubber, Natural rubber, Microporous foam
Silicone rubber, Synthetic rubber
Glass, Pressed glass, Float glass, Crystal glass, Mirror glass NoYes
