Product Details:
|
| High Light: | Robotic Welding Arm,Robotic Welding Equipment |
||
|---|---|---|---|
Fiber Laser Robot welding cutting machine for Metal Stainless Steel Aluminum Silver
Advertising Laser Welding Machine for Metal Letters
Metal profile except aluminum
Low noise,no pollution
Pulsed Nd:Y
|
Laser Source |
FL Fiber Laser Source |
||
|
Laser Power Output |
500W |
600W |
1000W |
|
Max.Positioning Speed |
50m/min. |
||
|
Working Area |
3000*1500mm(Optional) |
||
|
Run Distance of X Axis |
3040mm |
||
|
Run Distance of Y Axis |
1540mm |
||
|
Run Distance of Z Axis |
120mm |
||
|
Positioning Accuracy |
±0.025mm |
||
|
Repeated Positioning Accuracy |
±0.01mm |
||
|
Vertical Length of X&Y Axis |
0.03mm |
||
|
Transmission Way |
Gear Racking Transmission |
||
|
Linear Length of X&Y Axis |
0.02mm, 0.04mm |
||
|
Z Axis Floating Accuracy |
±0.05mm |
||
|
Machine Noise |
<75db |
||
|
Beam Quality |
Base Mode |
||
|
Power Supply |
3 Phase/380V/50Hz |
||
Introduction:
1. Aplication material:stainless steel,steel plate,iron plate and other metal and alloy;
2. Super Welder laser welding word machine advantages:high accuracy,can weld small and
complex typeface and LOGO,high speed,no chromatic aberration and trace after welding,with
beautiful appearance,no need processing;
3. Aim at advertising word industry,special king-size light path,arbitrary rotation for 360,higher
flexible range;
4.No protuberant welding spot on the welding surface,no need the process of polishing and
burnishing,saving working time,graceful and steady for the structure;
5. No noise and no pollution
6. Option CCD Monitor, welding result is much clearer.
Advantages of Welding Machine:
1.Laser Cooling Machine
2.Adopt high-power laser power devices
3.Continuous work for 24 hours
Parameters of Welding Machine:
| Max laser power | 200W |
| Laser wavelenth | 1064 nm |
| Monopulse Max power | 90J |
| Laser welding depth | 0.1-1.6mm |
| Pulse width | 0.1-20ms |
| Laser welding frequency | 0.5-40Hz |
| Laser spot size adjusting range | 0.2-2mm |
| Whole power consumption | ≤9KW |
| Power need | 220V ±10%/50Hz/40A |
| Standard configuration working table | 800*1000mm load200Kg |
| Sight positioning | CCD synchronism high definition camera |
| Laser device vertical travel | ≥200mm |
| Laser device horizontal direction | 200-800mm |
