200W 0.1mm - 1.6mm Robotic Cutting Machine For Stainless Steel

Brand Name:	CMC
MOQ:	1 set
Price:	according to the machine requirement
Payment Terms:	Down payment 30% T/T, 70% T/T before shipping
Supply Ability:	According requirement

Detail Information

Product Description

Detail Information

Place of Origin:

wuxi , china

Certification:

ISO,CE

Packaging Details:

Suitable for container shipping

Supply Ability:

According requirement

Highlight:

Robotic Laser Welding

Robotic Welding Equipment

Product Description

200W 0.1mm - 1.6mm Robot welding cutting machine for stainless steel

Specifications

Advertising Laser Welding Machine for Metal Letters
Metal profile except aluminum
Low noise,no pollution
Pulsed Nd:Y

Introduction:

1.Aplication material:stainless steel,steel plate,iron plate and other metal and alloy;

2.Super Welder laser welding word machine advantages:high accuracy,can weld small and complex typeface and LOGO,high speed,no chromatic aberration and trace after welding,with beautiful appearance,no need processing;

3.Aim at advertising word industry,special king-size light path,arbitrary rotation for 360,higher flexible range;

4.No protuberant welding spot on the welding surface,no need the process of polishing and burnishing,saving working time,graceful and steady for the structure;

5.No noise and no pollution

6.Option CCD Monitor, welding result is much clearer.

Advantages of Welding Machine:

1.Laser Cooling Machine

2.Adopt high-power laser power devices

3.Continuous work for 24 hours

Parameters of Welding Machine:

Max laser power	200W
Laser wavelenth	1064 nm
Monopulse Max power	90J
Laser welding depth	0.1-1.6mm
Pulse width	0.1-20ms
Laser welding frequency	0.5-40Hz
Laser spot size adjusting range	0.2-2mm
Whole power consumption	≤9KW
Power need	220V ±10%/50Hz/40A
Standard configuration working table	800*1000mm load200Kg
Sight positioning	CCD synchronism high definition camera
Laser device vertical travel	≥200mm
Laser device horizontal direction	200-800mm

200W 0.1mm - 1.6mm Robotic Cutting Machine For Stainless Steel 0

200W 0.1mm - 1.6mm Robotic Cutting Machine For Stainless Steel 1
