Gantry - hanging Welding Robotic Arm for Stainless Steel / Aluminum

Fiber Laser Welding Gantry-hanging Robot for Metal Stainless Steel Aluminum

Typical Applications:

• Friction Spot Joining
• Machine Tending
• Material Handling
• Material Removal
• Spot Welding

B Series Robots:

Click on a robot below to learn more. Note: images not shown to scale.

​

BX100S

Payload :100 kg
Axes :6
Reach :1,634 mm
Repeatability :±0.2 mm

BX100S

BX100N

Payload :100 kg
Axes :6
Reach :2,200 mm
Repeatability :±0.2 mm

BX100N

BX100L

Payload :100 kg
Axes :6
Reach :2,597 mm
Repeatability :±0.2 mm

BX100L

BX130X

Payload :130 kg
Axes :6
Reach :2,991 mm
Repeatability :±0.2 mm

BX130X

BX165N

Payload :165 kg
Axes :6
Reach :2,325 mm
Repeatability :±0.2 mm

BX165N

BX165L

Payload :165 kg
Axes :6
Reach :2,597 mm
Repeatability :±0.2 mm

BX165L

BX200L

Payload :200 kg
Axes :6
Reach :2,597 mm
Repeatability :±0.2 mm

BX200L

BX250L

Payload :250 kg
Axes :6
Reach :2,812 mm
Repeatability :±0.2 mm

BX250L

BX300L

Payload :300 kg
Axes :6
Reach :2,812 mm
Repeatability :±0.2 mm

BX300L

Welding - Spot Robots

B Series (Up to 300 kg Payload)

OPTIMIZED BODY SHOP ROBOTS

The B Series line of body shop robots were developed using Kawasaki's proven advanced technology and extensive automotive experience to take performance to the next level. The robust, yet lightweight slim design achieves the sought after optimization of functionality, flexibility and investment efficiency for maximum spot welding effectiveness and multi-purpose use.

Kawasaki’s new leading edge B Series spot welding robots offer through arm cable routing, a space saving design with a wide work envelope, as well as heavy-duty motors and advanced motion control technology to reduce manufacturing line build and digital engineering time, support installation in “high-density” applications and shorten cycle time by an average of 20%, all with greater spot control.

BT200L

Payload :200 kg
Axes :6
Reach :3,151 mm
Repeatability :±0.2 mm

BT200L

​

DOWNLOAD

Kawasaki B Series robots brochure

HIGH SPEED SPOT WELDING

Minimized net weight, heavy-duty motors and advanced motion control technology make the B Robot a champion sprinter. It excels at high speed short-pitch movements making it ideal for spot welding. The improved motion sequence by the servo welding guns, as well as the automatic calibration feature to optimize acceleration and deceleration of the gun speed, leads to a significant reduction in cycle time and results in maximum production.

SPACE SAVING DESIGN

Compared to conventional robots with similar payload capacity, the B Robots have a much smaller footprint and narrower body. The small footprint of these slim arm design robots allows for installation in "high-density" applications without impeding performance. In addition, the B Series robot line houses the cable harnesses within the robot arm, further reducing the amount of work space required and minimizing potential interference.

WIDE WORK ENVELOPE

The Kawasaki B Robot combines a long reach arm with a minimal amount of dead space for a wide work envelope and greater flexibility. Kawasaki Robotics' years of automotive experience have culminated into an optimal body shop design for both task effectiveness and multi-purpose usage.

INTEGRATED DRESS PACKAGE

The B Series robot line is manufactured using hollow reduction units for the upper arm. This allows for an internal dressing of the robot from the base to the tool mounting plate. With Kawasaki's integrated dress package, the manufacturing line build and digital engineering time is greatly reduced and interference with adjacent robots or peripheral devices is minimized.
