Product Details:
|
| Certification: | CE/ISO | Power: | Hydraulic,CNC |
|---|---|---|---|
| Raw Material: | Steel Stainless Sheet | Warranty: | 12 Months |
| Color: | Customized | Name: | CNC Hydraulic Press Brakes |
| Throat Depth: | 200-500 Mm | Application: | Construction Projects,press Brake,metal Bending,Galvanized Sheet,Steel Plate Bending |
| High Light: | 3200mm CNC Tandem Press Brake,320T CNC Tandem Press Brake,Steel plate hydraulic bending brake |
||
2-WE320T/3200 CNC Tandem Press Brake Machine With Electro-Hydraulic Servo System
CNC press brakes or CNC Metal benders are essentially machines designed to bend sheet metal and sheet metal components to various profiles and designs.
Press braking, or brake forming, is a metal deformation process that aligns a piece of sheet or plate metal along an axis. This is achieved by using a machine pressing tool (press brake) to clamp the metal piece between a punch and a die set for prearranged bending.
| TECHNICAL FEATURES | |||
| 1 | Type | Mult-machine Tandem Hydraulic CNC electro-hydraulic synchro | |
| 2 | Working force | 2X320Ton | |
| 3 | Length of table | 2X3200mm | |
| 4 | distance between frames | 2650mm | |
| 5 | Throat depth | 400mm | |
| 6 | Open height | 520mm | |
| 7 | Stroke | 250mm | |
|
8 |
Working Speed |
Unload | 70mm/s |
| Working | 7.5mm/s | ||
| Return | 75mm/s | ||
| 9 | Main motor | 2x22kw ( Siemens) | |
| 10 | CNC system |
Type: DELEM DA53T Delem Co., Netherlands CNC controlled 4 AXIS (Y1,Y2,X,R)+ bottom die with crowning system |
|
| 11 | Tool |
With 1 punching and 1 multi V block bottom die With front sheet supporting stand |
|
| 12 | Seal in the cylinders | SKF , OR NOK | |
| 13 | Hydraulic components | BOSCH-Rexroth - , Germany | |
| 14 | Hydraulic pump | SUNNY - , USA | |
| 15 | Linear Raster displayer sensor |
FAGUR,SPAIN |
|
| 16 | Main Electric Elements in cabinet | Schneider (French brand) | |
| 17 | weight | 2x19500 kg | |
| 18 | Overall size(mm) LxWxH | 2x3790x2510x3320 | |
| 19 | Packing: | With plastic cover | |
