Guardrail Roll Forming Machine

Highway 12m / Min Guard Rails Roll Forming Machine

Name

Highway 12m / Min Guard Rails Roll Forming Machine

Brand Name:	CMC
MOQ:	1 Set
Price:	Negotiate
Payment Terms:	T/T,L/C
Supply Ability:	50 Sets per month.

Detail Information

Product Description

Detail Information

Place of Origin:

wuxi,China

Certification:

CE, ISO

Name:

Highway Guardrail Roll Forming Machine

Speed:

8-12m/min

Weight:

65KG

Product Height:

81mm ± 5mm

Forming Method:

Cold Roll Formin

Main Voltage:

380V, 50Hz

Packaging Details:

The whole body covered with plastic bag. or according to the customers requirements.

Supply Ability:

50 Sets per month.

Highlight:

12m/min Guardrail Roll Forming Machine

,

3.5mm Guardrail Roll Forming Machine

Product Description

equipment structure diagram:

Advantages:

two waves highway guardrail roll forming machine

♥ As a manufacturer we are specialized in all kinds of roll forming machine.

♥ Good experience of 20 years to make roll forming machine.

♥ Choose the best material and components for export more then 40 countries.

♥ Provide best price,good quality and fast delivery.

Product name			two waves highway guardrail roll forming machine
NO.	Items		Parameters	Remark
1	Suitable Material	Type	GI/PPGI
		Width	Customized
		Thickness	1.5—3.5mm
2	Product Specifications	Length	Any length	Programmed
2	Product Specifications	Length Tolerance	±2mm
3	Working Speed	8-12m/min		Standard machine
4	Control System	Mitsubishi/Siemens PLC& transducer		Custom
5	Total Power	About 30KW		Up to final design
6	Total Weight	About 15T		Up to final design

II.Basic machine parameters

Mechanical properties and specifications of raw materials

Material: Q345B galvanized sheet

Thickness: 2.5～3.0mm

Width: 450-476mm

Weight: 65KG

Specifications of products

Product: by product drawing

Product width: 310mm ± 5mm

Product height: 81mm ± 5mm

Product specifications

Forming method: Cold roll forming

Production speed: ≤10m / min

Feeding direction: left feed

Main voltage: 380V, 50Hz

Unit total power: about 20.7KW

Drive shaft bearing: 6026

Turbo lift: SWL10-3 / 23-FU3

Main drive motor: YVP180M-4-15

Reducer: ZQ500-48.57

Wallboard material: A3

Shaft material: 40

Mold material: Gcr15

III,Overview of equipment structure

The equipment frame is processed by A3 steel plate, after aging treatment, 3-roller structure, 1 upper and 2 lower, the lower roller adopts a fixed structure, the upper roller adopts slider movement adjustment, and 3 sets of turbine box drive are driven by the motor to adjust the upper and lower The turbine box is connected by a connecting rod to ensure the synchronization of 3 sets of boxes, and the 3 independent wall plates are connected by a shaft to ensure the parallelism of the whole machine. The diameter of the roller shaft is 110mm. There are two sets of molds on the left and right, one for the inner arc and one for the outer arc, and a set of 15KW main motor. It is driven by a ZQ500 reducer, which drives the left and right lower shafts through gears.The gear module is 10m, one for each left and right.The product is processed through the operation console.

IV,Equipment configuration checklist

No

Part Name

Quantity

1

Forming mould

One set of molds on each side

2

15KW drive motor

1Set

3

Forming mold shaft

3Sets

4

Turbo lift

3Sets

5

Lifting drive motor

1Set

6

ZQ500 reducer

1Set

7

Electrical console

1Set

8

Equipment anchor bolt

1Set
