cnc laser cutting machine
500W 1500 X 3000 CNC Fiber Laser Cutting Machine For Sheet Plate
1. Effect chart of cutting sample processing
Advertising words Sheet metal processing Work piece cutting
2. ☆ Basic Introduction
Advertising words Sheet metal processing Work piece cutting
2. Basic Introduction
FL-3015 Fiber Laser Cutting Machine is achieved by powerful laser focused on object to cause instant melting and evaporation, with original fiber laser imported from IPG laser Group in Germany. Automatic cutting is controlled by digitalized mechanic system. This machine has condensed the technologies of laser, digital, and precise mechanics.
2.1. Split type designed and independent operation table. It can be moved according to the condition. Comfortable and easy operation.
2.2. Imported servo motor working table, traveling area 1500mm*3000mm.
2.3. Laser head can be adjusted through the Z axis, traveling area 0-100mm
3. Main Features
3.1. It can be widely used to cut plates such as: stainless steel, carbon steel, aluminum, etc.
3.2. Strong cutting ability: 500W type can stainless cut up to 8mm.
3.3. Low cutting cost: It can cut with air, and its cost is USD 0.5 - 1. The exact cost includes electricity 3-6 degrees per hour, lens protection USD 0.08 - 0.16 per hour, and no any other costs. If you use O2 or N2, The cost should be increased by USD 2.4 - 4.8. (As the shape and thickness are different, the gas consumption will be different.)
3.4. Fast cutting speed, high efficiency, safe operation, and stable performance.
3.5. Good quality, small distortion smooth and fine look outside.
3.6. Imported servo motor and gearing system to guarantee precise cutting. High cutting precision.
3.7. Dedicated software enables graphic or text to be instantly designed or processed. Flexible and easy operation.
4. Applied material
Applicable to cutting on plate or tube in stainless steel, carbon steel, alloy steel, spring steel, aluminum, copper, titanium, etc. It has excellent processing effect on kinds of hard brittle alloy steel.
5. Application Fields
Widely used in sheet metal processing, metal ware, kitchen appliance, high-resolute device, electric control box, auto parts, glasses, posters, crafts, lighting, and precise parts.
6. Main Structure Specification
500W-FL-3015 fiber laser cutting machine is made up of machine body, fiber laser, control box, air purification system and CNC control system.
|Center radiation wavelength||nm||1070-1080|
|Standard output power||W||500|
|Transmission fiber diameter||μｍ||≥50|
|Output power stability (Long term)||%||±2|
|1||Fiber laser||1||Original imported|
Speed expansion lens
|1||Adopts German technology and special designed. Optical lens directly affect the quality of facular, the affect the quality of cutting seam and flange, cutting speed and thickness.|
|3||Panasonic servo motor||1||
Panasonic servo motor and Panasonic driver.
Imported screw and rails from Taiwan
|5||Laser indication system||1||Semiconductor(Red light)|
Main equipment lead to good features: Laser generator and optical lens. We use Schneider electrical components.
|CNC operation table||It adopts steel structure welding, the stress failure processing, heavy duty rack structure, Imported rolling screw TBI, liner rail HIWIN, and Panasonic servo motor.||It has assistant equipment of discharging, tightly pressing and blanking.|
7. Main technical parameters
|Max. laser power||1000W|
|Positioning||Red light indication|
|Effective processing area||1500mm*3000mm|
|X/Y axis Repeat positioning precision||±0.03mm|
|Max. cutting thickness of carbon steel||≤8mm|
|Max. cutting speed of carbon steel||
0.8mm thickness stainless steel,12-14m/min,
1.0mm thickness stainless steel,10-12m/min
|Support documents||DXF etc.(support Auto CAD software,CorelDraw software)|
|Total power consumed||≤ 20KW|
3 phases 4 wires AC
8. Cutting Parameters
|Thickness (mm)||Material||Max cutting speed (m/min)||Assistant gas|
9. Technical Parameters
|Max laser power||500W(CW)|
|X axis stroke||3000m|
|Y axis stroke||1500m|
|X,Y axis positioning accuracy||±0.05mm|
|X,Y,Z axis repeat positioning accuracy||±0.03mm|
|X,Y single axis max no-duty speed||20min|
|X/Y axis max interaction speed||40min|
|X/Y max axial acceleration||1.0G|
|Max loading weight||500KG|
|Protection level of main power||IP54|
10. Equipment components
|4||Laser cutting head||USA lasermech||1|
|5||Water cooler||1 set|
11. Technical documents supplied
|2||Software using instructions||Set||1|
|3||Special laser cutting software||Set||1|
|5||Machine packing list||Piece||1|
12. INSTALLATION & COMMISSIONING
SELLER personnel will supervise the machine installation and commissioning
The service comprises of:
1. Supply of qualified technician(s).
2. Supervision of customer’s personnel for:
a) Positioning of machine
b) Running of cables and hoses from service entry point
c) Connection of electrical cables and gas hoses to the machine
3. Customer’s Responsibility
a) An air compressor (mainly used in pneumatic movements)
b) A bottle of liquid oxygen (preferable with a liquefier)
c) Power: 380V 50HZ 3 phases(with a 30KW regulator)
d) Gases, Air and Electrical supplies are available for the connection to the machine at the nominated points.
e) Customer is to ensure the site is clear prior to commencement of Installation, adjusting and training.
f) Supply of labors, carnages and insurance to unload machine and assist with installation work under the direction of DADE installation supervisor
g) Supply of mechanical fitters and one electrical fitter for the duration of the installation.
h) Supply of plate and consumables for commissioning test, machine alignment and training.
i) Weatherproof building, as warranty will be void if machine is subject to elements
j) Suitable concrete floor
1. At the completion of commissioning, SELLER technician will commence Training.
The customer shall provide sufficient material and consumables to ensure satisfactory completion to the training.
2. The training will comprise of:
a) Overview of machine
b) Control features and operation
c) Machine maintenance and adjustment
d) Supervised running of machine
The training of the machine operator is concurrent with the installation, therefore personnel must be available at all
