4 axis synchronised control CNC Punching Machine for turret punching press

Product Details:
Place of Origin: Wuxi, China
Brand Name: CMC
Certification: ISO9001-2000
Model Number: CKY3032A-1500X5000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: According to requirements
Packaging Details: Sutable for container shipping
Delivery Time: 50-60 days
Payment Terms: TT,LC,FOB,CIF
Supply Ability: Negociate

Detail Information

High Light:

cnc turret punching machine


sheet metal punching machine

Product Description

Turret CNC auto index punching machine of CKY3032A/1-1250X5000


Quick Detail:


Name Other name Brand Name CMC

Punching machine,

Punch and rolling machine,

High Efficiency CNC Mechanical Turret Punch Press Machine

Capacity Max. sheet thickness Carbon steel sheet 6.3mm
Stainless steel sheet 4mm
Max. sheet dimension 1250x5000
Advantage Thick turret, better guiding and higher precision; High speed hydraulic system can be adjusted stepless to improve punching speed Option It can be equipped with CNC controller: Fanuc and Siemens


> Newest type CNC turret punch with high speed, more efficiency and lower noise

> Thick turret, better guiding and higher precision, can be longer life-span of tooling

> Rapid loading and unloading tools

> Main parts (turret parts, components of index tool and reducer box, etc) supplied by our company

> High speed hydraulic ram head and hydraulic system of H+L from Germany, max 1750cpm with no load

> Brush and Wheel function, four-axis synchronised control function





The structure of the machine and characteristics:


Machine include: Body,Turret,Hydraulic system,Transmission system,Stationary worktable,Full floating clamps,Reposition system,The origin of the positioning pin device,Pneumatic and lubrication device,reduction gearbox,Electrical and control system,Tools,Programming Software etc ...

Feeding in the form of a plate material on the work table movement.


The work table :


Nylon brushes table,Table with nylon Brushes allows stainless steel and special surface materials can be processed without damage. The movement of sheet is quiet and smooth.Not be deformation, orientation stability, die wear small, turret for the 32 stations




Thick turret and Cast iron

Turret layout station code Numbers Punching diameter

Station code Numbers Punching diameter
A 16 3~12.7 mm
B 8 ≤31.7 mm
C 4 ≤50.8 mm
D 2 ≤88.9 mm
IT(Auto index) 2 ≤50.8 mm











The originality of using upper and lower floating clamps. The floating clamps make the loading easy, optimizes its working condition and produces big clamping force. In addition, the clamp is of gutter type connection for easy movement.


Hydraulic system:

It is safe, reliable , noise-low and automatic hydraulic overload protection with a stable punching force in the complete stroke.hydraulic system ensures the machine to be reliable and has high performance of power, reduces vibration and noise.




This machine adopts automatic lubrication,equipment under working condition without manual lubrication,The lubricating oil to the lubrication points, reduce the movement friction, improve the service life of the machine, convenient user maintenance work.

Movement structure: The machine movement structure of imported Taiwan HIWIN company is a manufacturer of precision ball linear guide rail,Large guide distance precision ball screws and Japanese NSK company is a manufacturer of precision bearing pairs. High precision, fast speed.


The tooling:


The international universal tooling is of thick turret long guide series, with a high hardness, anti-abrasion ability and good guidance, a long tool life and no shim needed after regrinding. The work range can be expanded with auto indexing stations.


CNC system:


The machine takes the world-famous FANUC or SIEMENS control

system and AC servo system. Features: Universal RS232 standard interface,Chinese and English text are available, mighty diagnostic function, Gripper and punching head auto protection, The international universal G code program. On line data transfer reduces down time and raises productivity.


The machine can be processed materials

The machine through the two positioning, can be processed 1500x5000mm sheet




No Project name parameter
1 CNC turret punching press CKY3032/4axis(X,Y,T,C)
2 Punching force 300 KN

Number of tool stations

(Including 2 index stations)

4 Max. sheet size (One reposition) 1250x5000 mm
5 Max. punching diameter ∮88.9 mm
6 Max. sheet thickness 6 mm
7 Slide guide stoke 40 mm
8 Punching frequency 600 h/min.
9 X/Y Max. positioning speed 60 m/min
10 Turret rotation 30 r/min

Machining accuracy

(according Jinqiu standard, 200x300mm square)

±0.1 mm
12 Repeat positioning accuracy ±0.02 mm
13 Oil tank capacity 250 L
14 Compressed air 0.6 M.pa
15 Electrical energy 28 KVA
16 Main motor power 11 KW
17 Overall dimension


2175 mm

18 Weight 13022 Kg
19 Machine structure O-Type































Main Configuration


No Project name manufacturer
1 Hydraulic system H+L, Germany
2 FANUC CNC system FANUC,Japan
3 Servo motor FANUC,Japan
4 Precision ball linear guide Taiwan HIWIN
5 Precision ball screws Taiwan HIWIN or Nanjing Gongyi
6 Pneumatic component Japan SMC+ Chinese one
7 Automatic programming software CNC Kad
8 Lubrication system Domestic brand

Punching Tool for the standard configuration

Note: according to different prices for sure


WILSONTOOL, according customer requirement


















Trade terms


Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Metal pallet
Delivery Time: 50-60 days
Payment Terms: Ex works/ FOB SHANGHAI/ CIF
