Cantilever Type Small CNC Plasma Cutting Machine , Flame cutter for Thin Plate

Product Details:
Place of Origin: wuxi ,china
Brand Name: CMC
Certification: ISO
Model Number: CNC3-1500
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: according to the machine requirement
Packaging Details: Suitable for container shipping
Delivery Time: according to the machine requirment
Payment Terms: FOB/CIF
Supply Ability: According requirement

Detail Information

High Light:

steel plate cutting machine


cnc plasma cutting equipment

Product Description

Function and Application:


lt is mainly applied to the cutting of middle-small size middle thin plate.
It is compatible with the PC machine of gantry type digital control cutter.
It can be used to cut any plane geometric figure.
According to the needs of users,it can be used in flame cutting,plasma cutting, fine plasma cutting etc.
● lt iS small and exquisite and stable to operate with three dimensional coordinate control which is named as"digital control exquisite cutting robot".



Main Performance:


● The crossbeam frame adopts single arm rotary structure,which is high strength,rigidity design with removal stress processing,and applies steel guide rail compounded with straight guide rail, which has such functions as good stability and high precision and not distorfion;
● Drive system adopts Panasonic digital AC servo system;
● CNC system can be equipped with START FL-CNC, EDGE series or according to requests of customers;
● Automatic ignition,perforation and capacitance height-regulating,plasma cutting equipped with utomatic arc voltage regulating device
● Dry type plasma cutting equipped with USA Thermadyne CUTMASTER 151 power as well as selected other intemational well-known brands.


Technical Parameters:


Specifications Model CNC3-1500
Specifation & Model length 4000mm Selected by user's requirement
Effective cutting length 3000mm
Transve rse guide rail width 1700mm
Effective cutting width 1500mm
Cutting thickness Flame:6-150mm Flame Plasma determined by selected cutting power
Cutting speed 50-1000mm/min
Lost motion speed 50-3000mm/min
Cutting roughness Ra12.5mm
Cutting precision ±0.5mm/m
