CNC Hydraulic Press Brake Throat Depth 1000mm For Making Light Pole

Brand Name:	CMC
MOQ:	1 set
Price:	negotiation
Payment Terms:	30% T/T Down Payment,70% T/T Before Shipping
Supply Ability:	According to requirement

Detail Information

Place of Origin:

Wuxi, China

Packaging Details:

Metal pallet, Suitable for container shipment, both marine and inland transportation

Supply Ability:

According to requirement

Highlight:

Product Description

TECHNICAL FEATURES
1	Type		Mult-machine Tandem Hydraulic CNC electro-hydraulic synchro
2	Working force		2X650Ton
3	Length of table		2X6000mm
4	distance between frames		4800mm
5	Throat depth		1000mm
6	Open height		960mm
7	Stroke		320mm
8	Working Speed	Unload	70mm/s
		Working	7.5mm/s
		Return	75mm/s
9	Main motor		2x45Kw
10	CNC system		Type: DELEM DA 53T Delem Co., Netherlands 2 Axis(Y1,Y2)+ table crowing system
11	Tool		The tool detail see attachment
12	Main Electric Elements in cabinet		Schneider
13	Seal in the cylinders		SKF or NOK type
14	Hydraulic pump		SUNNY (USA BRAND)
15	Main hydraulic component		BOSCH-Rexroth - , Germany
16	Raster displayer		FAGOR, SPAIN
17	weight		2x62000kgs
18	Overall size(mm) LxWxH
19	Packing:		The machine should be disassemble during transportation. Our engineer should go to customer to assemble and adjust it.
