High speed hydraulic CNC plate punching machine / equipment with LCD computer control

Product Details:
Place of Origin: Wuxi, China
Brand Name: CMC
Certification: ISO9001-2000
Model Number: Q25HB
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: According to requirements
Packaging Details: Sutable for container shipping
Delivery Time: 50-60 days
Payment Terms: TT,LC,FOB,CIF
Supply Ability: Negociate

Detail Information

High Light:

sheet metal punching machine


cnc plate punching machine

Product Description

Detailed Product Description


Quick Detail:


Name Other name Brand Name CMC
CNC TURRET PUNCHING MACHINE 1 sheet / profiles CNC punching equipment;CNC punch press;Plate CNC punching machine; Capacity Max. sheet thickness ~12mm
Max. sheet dimension 1250x2500
Advantage better guiding and higher precision; High speed hydraulic system can be adjusted stepless to improve punching speed Option It can be equipped with CNC controller





1. Automatic CNC punch press patented bed X, Y spacing of the feed to increase the rail bed 1600mm, significantly improve the processing precision and stability

2. The company CNC punch press dedicated system, field programming, background programming, industrial brand LCD computer control, with other computers, local area network, the World Wide Web easy to connect

3. The mold library, the program automatically converts graphics editing and CAD, CAD drawings which can be directly generated by processing complex graphical programming has become quick and easy. screen display is not just boring X, Y coordinates, but the product pictures and processing real-time apparent, easier operation

4. For convenient operation, batch processing, simplifying this procedure, greatly improving production efficiency and reduce the chance of error. Auto Repeat precise positioning plate .

5. Under the CNC control the Mold can jog, powerful mold library management, and will enter a variety of punch size mold library, readily available, management is very intuitive

7. Pneumatic floating clamp, universal ball steel platform; electrical cable with shielded to prevent interference with the effective

8. 1600mm wide rail spacing, design to precision processing of large panel, super-smooth transmission; body supporting platform and the main platform of integrated design, support platform with the plates move together, the level of resistance, support better, put an end to table X, Y-axis dynamic offset

9. Centralized lubrication pump

10. Scrap collecting devices prevents splashing.





Press Capacity 630KN 1000KN 1600KN
Max thickness (mild steel sheet) 6~8mm 6~10mm 6~12mm
Max. X-axis stroke 3000mm
Max. Y-axis stroke 1200mm
Max. sheet metal size 3000mm×1200mm
Throat Depth 800mm or according customer requirments
Max. processing weight 126Kg 157kg 190kg
punching speed 50HPM 45HPM 38HPM
worktable moving speed 30m/min
machining accuracy ±0.1mm
Working stations(can be design according customer requirments) 7 9 9
PRESSURE AIR flow, pressure 0.1m3/min, 0.5MPa(5.0kgf/c㎡)
Main motor power 5.5KW 11KW 15KW
machine weight 10tons 17tons 21tons


Note: (1). the tool is special design for thick metal sheet.

          (2)The tools arrangement can be designed according to user’s products.


3. Product basic information


Place of Origin: China
Brand Name: CMC
Model Number: Q25HB



4. Product trade terms


Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Metal pallet
Delivery Time: 50-60 days
Payment Terms: Ex works/ FOB SHANGHAI/ CIF
