Product Details:
|
| Power: | Hydraulic,CNC | Machine Type: | Press Brake,Beading Machine |
|---|---|---|---|
| Condition: | New | Material / Metal Processed: | Stainless Steel,Carbon Steel,Aluminum |
| Automation: | Automatic | ||
| Highlight: | 250 ton Cnc Hydraulic Press Machine,Stainless Steel Cnc Hydraulic Press Machine,Stainless cnc hydraulic press brake machine |
||
| TECHNICAL FEATURES | ||
| 1 | Type | Hydraulic CNC electro-hydraulic synchro |
| 2 | Working force | 250 T |
| 3 | Length of table | 4000 mm |
| 4 | Distance between frames | 3100 mm |
| 5 | Throat depth | 400 mm |
| 6 | Open height | 560 mm |
| 7 | Stroke | 250mm |
| 8 | Speed |
Fast down speed: 70mm/s Working speed: 7mm/s Return speed: 60mm/s |
| 9 | Main motor | 15 kw |
| 10 | CNC system |
TYPE: DELEM DA65w Delem Co., Netherlands 4 Axis(Y1,Y2,X,R)+ 1 working table compensation axis |
| 11 | Tool | With 1 punching and 1 bottom die |
| 12 | Main Electric Elements in cabinet | Schneider |
| 13 | Seal in the cylinders | NOK, made in Japan |
| 14 | Hydraulic components | BOSCH-Rexroth - , Germany |
| 15 | Hydraulic pump | SUNNY,USA |
| 16 | Linear Raster displayer sensor |
FAGUR,SPAIN |
| 17 | Gross weight | 17300kg(net 17000 kg) |
| 18 | Overall sizes(mm) LxWxH | 4210x2500x3065 |
| 19 | Packing: |
With plastic cover Transportation: 20’OP
|
