Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment

Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment
Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment

Large Image :  Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment

Product Details:
Place of Origin: china
Brand Name: XLY
Certification: ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: standard export packing
Delivery Time: 90days
Payment Terms: L/C, D/A, D/P, T/T

Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment

Description
After-sales Service Provided: Engineers Available To Service Machinery Overseas Condition: New
Warranty: 1 Year Voltage: Customers Local Voltage
Type: Hot Dip Galvanizing Zinc Bath: Ceramic Or Metal Bath
High Light:

hot dip galvanising equipment

,

hot dip galvanizing machine

Zinc smoke collection system

Proprietary characteristics



1..Zinc smoke collection system adopts side sucking method to collect zinc smoke.

2.Side collection covers are put on both sides of the zinc pot , each one is independent.

3. Each side has a regulator, which adjusts the zinc smoke collection effect of each side suction port to be consistent.

4. Guide plate is set on the upper edge of the zinc pot mouth,The effect of collecting zinc smoke can be better.

5.The side suction devices on both sides of the zinc pot are connected together through a three-way connection at the end of the zinc pot.

6.Fans use negative pressure to extract zinc smoke.

7.Zinc smoke is discharged outward through chimneys.

Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment 0





Zinc smoke treatment system



Proprietary characteristics

1.Zinc smoke treatment system uses bag filter to purify zinc smoke.

2.Bag filter is a kind of dust removal device which uses needling fibers or woven bag type filter elements to collect solid particles in dusty gases.

3.The filtration principle is:When the dust particles are wrapped around the filter cloth, they are intercepted by the collision of the fibers due to the inertial force.

4.It adopts pleated filter bag, which is small in size and large in filtration area.

5.Use compressed air to regularly remove dust on the surface of bag filter. An air bag is designed on the dust collector to store compressed air.

6.A dust hopper is arranged at the bottom of the dust collector body for dust collection and manual collection.

7.use sequential controller and solenoid valve to adjust soot blowing intensity.

8.The working process of the dust collector is :filtration and dust removel are alternate and repeat..

The machine includes the following items:

  1. Dust collector body
  1. Filter cartridge
  1. Air bag
  1. Solenoid valves
  1. Sequence Controller



Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment 1

Zinc Smoke Collection And Treatment System For Hot Dip Galvanizing Equipment 2



Proprietary characteristics
