Product Details:
|
| Power: | Hydraulic,CNC | Machine Type: | Press Brake, Beading Machine |
|---|---|---|---|
| Condition: | New | Material / Metal Processed: | Stainless Steel,Carbon Steel,Aluminum |
| Automation: | Automatic | Color: | Customized |
| Name: | CNC Hydraulic Press Brakes | ||
| High Light: | carbon steel cnc hydraulic press brake,carbon cnc hydraulic press brake machine,Carbon Steel nc press brake |
||
160 Ton 4000 4mm Cnc Hydraulic Press Brake
Hydraulic press brakes are used to bend and fold metal by pressing it into a die. These presses are designed for both specialized sheet metal work and continuous production applications. They can handle tough industrial production jobs from single-cycle operations to automated cell components.
Detailed Product Description:
| CNC Control System: |
DA-53T |
Function: | Bending Steel Plates |
| Product Name: | CNC Hydraulic Press Brake | Steel Sheet Thickness: | 4mm |
| Steel Sheet Width: | 4000mm | Use: | Metal Plates |
Specifications:
Main Technical Features
| NO. | Name | Value | Unit | Remark | |
| 1 | Working force | 1250 | KN | ||
| 2 | Length of table | 4000 | mm | ||
| 3 | Distance of column | 3100 | mm | ||
| 4 | Throat depth | 430 | mm | ||
| 5 | Open height | 490 | mm | ||
| 6 | stroke | 200 | mm | ||
| 7 | Speed of ram slide block | Approach | 100 | mm/s | |
| Working | 8.5 | mm/s | |||
| Return | 75 | mm/s | |||
| 8 | Main motor | 7.5 | KW | ||
| 9 | Overall dimension | Length | 4250 | mm | |
| Width | 2140 | mm | |||
| Height | 2870 | mm | |||
| 10 | Weight | 11300 | Kg | ||
| 11 | Volume of oil tank | 380 | L | ||
