Benchtop Hydraulic Steel Plate Press Brake Machine 63T / 2500mm

Benchtop Hydraulic Steel Plate Press Brake Machine 63T / 2500mm
Benchtop Hydraulic Steel Plate Press Brake Machine 63T / 2500mm

Large Image :  Benchtop Hydraulic Steel Plate Press Brake Machine 63T / 2500mm

Product Details:
Place of Origin: Wuxi,china
Brand Name: CMC
Model Number: WC67Y-63/2500
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: Metal pallet
Delivery Time: According requirement
Payment Terms: Down Payment 30% T/T ,70% T/T Before Shipping
Supply Ability: According requirement

Benchtop Hydraulic Steel Plate Press Brake Machine 63T / 2500mm

Description
Highlight:

press brake equipment

,

metal bending machine

Detailed Product Description:



CNC Control System:

Delem DA-41

Estun E10 E200

Jin Qiu DTC800



Function: Bending Steel Plates
Product Name: Press Brake Machine Steel Sheet Thickness: 3mm
Steel Sheet Width: 2500mm Use: Metal Plates





Quick Detail:

Hydraulic Steel Plate Press Brake Machine 63T/2500mm

1. punch force: 630KN

2. bending max steel sheet width :2500mm

3. bending max steel sheet thickness :3mm





Description:



1. The steel-welded frame could make sure high strength, high rigidity and high accuracy.

2. Using of mechanical forced synchro system, both sides of sliders move in parallel by synchro axis.

3. Deflection compensation unit is installed in the upper mold,Upper mold clamping device is an option.

4. When NC press brake, X-axis backgauge is driven by servo motor ,adoapted ball-screw and linear guide way.

5. When NC press brake, ram stroke are controled by servo moto,it could make sure higher positioning accuracy.





Applications:



Press Brake Machine is widely used in large steel structure, steel tower, truck carriage, electric cabinet, decoration industrial. With different dies provided, the subscriber can get the metal plate bent into different shapes of work pieces.



Specifications:



Main Technical Features

NO. Name Value Unit Remark
1 Working force 630 KN
2 Length of table 2500 mm
3 Distance of column 2050 mm
4 Throat depth 250 mm
5 Open height 340 mm
6 stroke 100 mm
7 Speed of ram slide block Approach 70 mm/s
Working 10 mm/s
Return 60 mm/s
8 Main motor 5.5 KW
9 Overall dimension Length 2750 mm
Width 1725 mm
Height 2215 mm
10 Weight 4500 Kg
11 Volume of oil tank 240 L













































































Competitive Advantage:



1) Our machine performance quality and chcheap, known in the industry.

2) One year guarantee.

3) Fast and high quality after-sales service.

4) We can design the machines according to customers’ special requirement.

5) We have professional team for service.
