160 Ton 4000 4mm Cnc Hydraulic Press Brake

Product Details:
Place of Origin: Wuxi-China
Brand Name: CMC
Model Number: WE67K-125/4000
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: negotiation
Packaging Details: Metal pallet
Delivery Time: According requirement
Payment Terms: T/T, L/C
Supply Ability: According requirement

Detail Information

Power: Hydraulic,CNC Machine Type: Press Brake,Beading Machine
Condition: New Material / Metal Processed: Stainless Steel,Carbon Steel,Aluminum
Automation: Automatic Color: Customized
Name: CNC Hydraulic Press Brakes
High Light:

4000 cnc hydraulic press brake

,

160t cnc hydraulic press brake

,

4mm cnc hydraulic press brake

Product Description

Detailed Product Description:


CNC Control System:

DA-53T
DA-66T



Function: Bending Steel Plates
Product Name: CNC Hydraulic Press Brake Steel Sheet Thickness: 4mm
Steel Sheet Width: 4000mm Use: Metal Plates






Specifications:

Main Technical Features

NO. Name Value Unit Remark
1 Working force 1250 KN
2 Length of table 4000 mm
3 Distance of column 3100 mm
4 Throat depth 430 mm
5 Open height 490 mm
6 stroke 200 mm
7 Speed of ram slide block Approach 100 mm/s
Working 8.5 mm/s
Return 75 mm/s
8 Main motor 7.5 KW
9 Overall dimension Length 4250 mm
Width 2140 mm
Height 2870 mm
10 Weight 11300 Kg
11 Volume of oil tank 380 L
