Flanging Machine / Φ 6500×40mm Dished End Machine for boilers and separation equipment

China Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment supplier
Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment supplier Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment supplier Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment supplier Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment supplier Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment supplier

Large Image :  Flanging Machine / Φ 6500×40mm Dished End Machine for boilers and separation equipment

Product Details:

Place of Origin: wuxi, china
Brand Name: DONGYANG
Model Number: FBJ Φ6500×40mm

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: According to requirements
Packaging Details: Sutable for container shipping
Delivery Time: 120days
Supply Ability: Negociate
Contact Now
Detailed Product Description

Quick Detail:



Name Other Name Brand Name
Flanging machine

Edging machine

Spinning machine

Feature

Leading quality, unique design, good handling, cost-effective.

Can be customized according to customer's requirements.

Capacity

Can make Φ6500×40mm dished end.



Advantages

With this pressing machine,the spinned dished end have smooth surface,small round mark, good roundness, high productivity

Other model can be customized according to customer's demands





Extensive applications of dished end:


Dished end is a major part which on the end cap of pressure vessels,such us storage tanks, heat exchangers, towers, reaction kettles, boilers and separation equipment. So our machine is quite wildly uesd in these fields.




Specifications



No Name Parameter
1

Max. plate thickness S

Q235 40mm
2

Min. plate thickness S

Stainless steel 3mm

3

Max. plate radius

R820mm
4

Min. plate radius

R30mm
5

Max diameter of ellipsoidal dish end

D=6500
6

Min diameter of ellipsoidal dish end

D=1700
7

Forming wheel axle diameter

D=280mm
8

Forming wheel rotation power

N=67KW/55KW double speed





Additional requirements



1, The pressure of oblique cylinder, front cylinder, clamping must show on pressure gauge and could be adjustable. The speed of front and rear cylinders could be adjustable. Hydraulic station pressure could show on gauge and adjustable

2, A pressure wheel (mounted on the axle), and quenching treatment HRC46 ~ 50.

3, 17 forming wheels, R30,R50,R80,R100,R150,R200,R250,R300,R350,R400,R450,R500,R550,R600,R650,R700,R760,R820. Material QT600-3, marked with stamp. Forming wheel must have good abrasion resistance; dish end must have good gloss after spinning.

4, Make sure clamping cylinder work normally

5, Nut (for screw) strength: abrasion resistance must ZHA166-6-3-2 (aluminum brass), that is 9-4 copper.

6, Inner height 3383mm Total height 4883mm.





Dished end making process and other suggested machines:



1.CNC Gantry Flame and Plasma Cutting Machine

We use this machine to cut the plate. If small dish end, we can cut a whole circle directly, if big dish end, in order to save material, we usually cut two pieces, then weld them into whole circle.



2.Grinder

After welding, we use this small trolley to grind the welding joint and get flat material.



3. YGJ Φ 6500×40mm Pressing machine

 Flat material is loaded into pressing machine. This machine’s piston rod of the master cylinder moves up and down to drive the upper tool to press the raw plate to become the required concave shape.

Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment



Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment

4.FBJ Φ6500×40mm Flanging Machine with toolings

we load this concave shape plate into next machine: dish end flanging or edging machine. The clamping frame functions as the fix and free rotation of dish ends. Pressure wheels make movements based on certain round arc and put force on the dish end blank to make it rotate constantly to form dish ends and make thickness reduction minimum to achieve the ideal state.

Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment



5.Edge trimmer

  We use it to cut dished end uneven edge.

Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment



6.Dished end

  Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment



Factory name: Wuxi Dongyang Spinning Equipment Co.,Ltd

Flanging Machine /  Φ 6500×40mm Dished End Machine for boilers and separation equipment



Contact Details
Wuxi CMC Machinery Co.,Ltd

Contact Person: Mr. Wu

Send your inquiry directly to us (0 / 3000)
